Enhancing Beam Expanders with Relay Lenses: A Comprehensive Guide

Beam expanders are crucial components in optical systems, amplifying and adjusting the size of light beams for various applications. When integrating relay lenses into beam expander systems, it's essential to understand how these lenses can optimize performance and maintain system magnification.


Relay lenses are added to beam expander systems to extend the overall length of the system while maintaining or altering the system's magnification. The total length of the beam expander increases by the sum of the focal lengths of the two surfaces of the relay lens. The system magnification is given by:

Msystem = (MKeplerian) (Mrelay)

MKeplerian = f2/f1: The magnification of the Keplerian beam expander.

Mrelay = fr1/fr2: The magnification of the relay lens.

Maintaining Original Magnification with Relay Lenses

To maintain the original magnification of the beam expander when adding a relay lens, the focal lengths of the two surfaces of the relay lens must be equal, ensuring that Mrelay = 1. This configuration allows the relay lens to extend the system's length without altering its magnification.

Why Equal Focal Lengths Matter

Equal focal lengths in the relay lens ensure that the optical system retains its original magnification, which is crucial for maintaining precision in applications like laser processing, microscopy, and imaging systems. By maintaining the system's magnification, equal focal lengths prevent distortions and ensure consistent performance.

Bena Optics offers high-quality double convex lenses designed to meet the exacting standards of optical precision. Our lenses are crafted to provide equal focal lengths, ensuring optimal performance in beam expander systems.

Precision Engineering: Our double convex lenses are meticulously manufactured to ensure equal focal lengths and high accuracy.

Wide Range of Applications: From laser systems to microscopy, our lenses are designed to enhance performance across various fields.

Advanced Coatings: Reflective and anti-reflective coatings ensure optimal functioning and minimal loss of light.

Applications of Relay Lenses in Beam Expanders

Relay lenses integrated with beam expanders are widely used in:

Laser Systems: For precise beam expansion and alignment in laser processing and cutting.

Microscopy: To maintain magnification and clarity in high-resolution imaging.

Imaging Systems: For consistent and precise image magnification in cameras and optical instruments.
